UYGULAMA

The ESP-LXME provides flexible features and modular options that make the controller ideal for a wide variety of applications including light- commercial, commercial, and industrial irrigation systems. Modular options include modular station capacity, flow sensing, metal case and pedestal, ETC Manager Smart Cartridge, and IQ v2.0 Central Control Communication Cartridges. These options are field installed and can upgrade and enhance the ESP-LXME at any time in the future.

 GENEL ÖZELLIKLER

• Large LCD display with easy to navigate softkey user interface
• Hot-swappable modules, no need to power down the controller to add/remove modules
• Dynamic station numbering eliminates station numbering gaps
• Weather Sensor input with override switch
• Master valve/pump start circuit
• 6 user-selectable languages
• Non-Volatile (100- year) program memory
• Standard 10kV surge protection
• Front panel is removable and programmable under battery power
• Optional Flow Smart Module™ with Learn Flow utility and flow usage totalizer
• FloWatch™ protection for high and low flow conditions with user defined reactions
• FloManager™ manages hydraulic demand, making full use of available water to shorten total watering time
• SimulStations™ are programmable to allow up to 5 stations to operate at the same time
• Water Windows by program plus Manual MV Water Window
• Cycle+Soak™ by station
• Rain Delay
• 365-Day Calendar Day Off
• Programmable Station Delay by program
• Normally Open or Closed Master Valve programmable by station
• Weather Sensor programmable by station to prevent or pause watering
• Program Seasonal Adjust
• Global Monthly Seasonal Adjust

 TEKNIK ÖZELLIKLER

• Station timing: 0 min to 12 hrs
• Seasonal Adjust; 0% to 300% (16 hrs maximum station run time)
• 4 independent programs (ABCD)
• ABCD programs can overlap
• 8 start times per program
• Program Day Cycles include Custom days of the week, Odd, Odd31, Even, & Cyclical dates
• Manual station, program, test program
• Input required: 230 VCA ± 10%, 50 Hz
• Output : 26,5 VCA, 1,9 A
• Power back-up: Lithium coin-cell battery maintains time and date while nonvolatile memory maintains the programming
• Multi-valve capacity: Maximum five 24 VAC, 7VA solenoid valves simultaneous operation including the master valve, maximum two solenoid valves per station
